Clarke
®
Operator’s Manual - FOCUS II MID-SIZE AUTOSCRUBBER
®
71483A - 101 -
Clarke
®
FOCUS II MID-SIZE AUTOSCRUBBER
®
Frame Assembly Parts List 9/10
Ref # Part No. Description Qty
30 980614 Washer, 1/4” Starlock External 3
31 980205 Washer, .31 ID x 1.06 OD 2
32 69639A Strap, Static 1
33 88612A Washer, Lock M10 10
34 88614A Screw, M10-1.5 x 20MM 6
35 61949A Bracket, Ground Strap 1
36 41081A Cord, Charger NEMA NOTE 1 1
37# 56380160 Transaxle TSBCL2010-25, TSBCL2009-02 1
[ ] 40628A Carbon Brushes, Transaxle (Set) 1
40 88611A Washer, Flat M10 6
41 88613A Screw, M10-1.5 x 16MM Hex 4
42 9095202000 Caster, Rear 1
43 80196A Nut, M5-.8 Nylock SS 4
44 61934A Bracket, Brake 1
45 54772A Clamp, Toggle Straight Line 1
46 80249A Screw, M5-.8 x 12MM Hex 4
47 920160 Nut, 5/16 Jam Hex 1
48 962157 Screw, 5/16-18 x 1.25 Hex Hd 1
49 60580A Wheel, 10” Foam Filled 2
50 980652 Washer, 5/16 Lock 8
51 80183A Bolt, M8-1.25 x 20, Hex 8
52 980657 Washer, Lock 1/4 4
53
# 41077A Charger, Battery NOTE 1 TSBCL2009-04 1
54 61931A Chassis, Wldmt 1
55 80223A Nut, M10-1.5 Nylock 1
56 9096113000 Spacer 2
57 54689A Gas Spring 500N 1
58 71017A Label, Moving Parts 1
[ ] 41062A Harness Chrg Jumper NOTE 2 1
[ ] 40512B Charger Battery 25 Amp NOTE 2 1
[ ] 40297A Cable Charger Adapter1 NOTE 2 1
# = Revised or new since last update
[ ] = Not Shown
NOTE 1: Only used on models with on-board charger.
NOTE 2: Only used on models without on-board charger.
revised 9/10
Ref # Part No. Description Qty
1 88633A Screw, M8 x 85 Hex Head 2
2 170860 Washer, Flat 5/16 4
3 61937A Spacer, .590 OD x .328 ID 2
4 88620A Screw, M12 x 90M Hex 1
5 9097456000 Lever 1
6 88635A Screw, M8 x 75 Hex Head 1
7 9096112000 Spacer 2
8 9097402000 Actuator (for all models except BOOST) 1
40280A Actuator (for BOOST 28/32 models only) 1
9 80198A Nut, M8-1.25 Nylock S.S. 3
10 88618A Nut, M12 Nylon Insert 1
11 88626A Screw, M6-1 x 40MM Hex 1
12 87026A Washer, 1/4 Flat S.S. 6
13 1462258000 Spacer 2
14 80199A Nut, M6-1.00 Nylock S.S. 8
15 9097368000 Support, Jack Motor 1
16 88616A Screw, M10 x 75M Hex 1
17 87054A Washer Fender .375 5
18 80214A Screw, M6 x 1 x 12 2
19 59789A Valve, Solution 1
20 30828A Hose, Clear x 25.00 Long 1
21 88624A Screw, M5 x 12MM Hex Self Tap 4
22 61932A Bracket, Solution Valve 1
23 88623A Nut, M4-.7 Nylock Insert 2
24 9097370000 Bracket, Filter 1
25 9097404000 Filter, Water 1
26 722030 Clamp, Hose 4
27 80057A Screw, M4-.7 x 10 2
28 30829A Hose, Clear x 3.00 Long 1
29 57994A Screw, M6-1 x 20 9
To Next Page
