Clarke
®
Operator’s Manual - FOCUS II MID-SIZE AUTOSCRUBBER
®
71483A - 91 -
Clarke
®
FOCUS II MID-SIZE AUTOSCRUBBER
®
Electrical Box Assembly Drawing 1208
Ref # Part No. Description Qty
1 80249A Screw, M5-.8 x 12MM Hex 3
2 980643 Washer, 7/16 OD x .036 THK 3
3 962027 Screw, 8-32 x 1/2 P.H. 3
4 61933A Plate, Electrical 1
5 41068B Controller, I-Drive 24V Traverse 1
6 80380A Screw, 8-32 x 1 1/4” P.H. 2
7 41810A Contactor, Brush 24V 1
8 980614 Washer, 1/4” Starlock External 2
9 85391A Screw, 1/4-20 x .625 Pan Hd. 2
10 Ref. Relay Holder
(included in 41061A Harness)
1
11 54764A Insert, Hex 1/4-20 UNC 2
12 41075A Relay 1
13 Ref. Fuse Holder
(included in 41061A Harness)
1
14 41073A Fuse, 30A (see WARNING below) 1
15 962979 Screw, 6-32 x 1/2 PN ST PH 2
16 920056 Nut, 6-32 E.S.N.A. Nylock 2
17 Ref. Fuse Holder
(included in 41061A Harness)
1
18 41074A Fuse, 60A (see WARNING below) 1
19 41069B Relay, i-Drive 24V Traverse 1
20 54763A Insert, Hex #8-32 UNC 7
NI 41065B Harness, Traverse 1
NI 41061A Harness, Machine 1
WARNING: To reduce the risk of fi re, when replacing
fuse, replace only with same type and rating
of fuse that comes with machine.
