Clarke 1700 - Assembly Parts List 10;02

Clarke
®
Ultra Speed Burnisher 1700
Assembly Parts List 10/02
Ref # Part No. Description Qty
1 50774A Knob 2
2 170860 Washer, Flat 12
3 62423A Clamp 1
4 49310A Wire 1
5 32369A Cover (gray) 1
32369B Cover (black) 1
6 44201A Light (rectangular) 1
34259A* Light (round) 1
7 85517A Screw 2
8u 70673A Label, Clarke 1
9 41403A Circuit Breaker 1
10 699202 Cable Tie 1
11 45025A Motor (includes #12) 1
12 915044 Key (included w/#11) (1)
13 57262A Pulley 1
14 60193A Axle 1
15 20006A Frame 1
16 30035A Bumper 1
17 170820 Screw 4
18 52462A Ring, Retaining 1
19 902550 Bearing 2
20 980638 Lockwasher 8
21 85703A Screw 4
22 60492A Spindle 1
23 50921A Belt 1
24 57261A Pulley 1
25 56925A Pad Driver (Includes 27, 31) 1
26 962714 Screw 1
27 57369A Retainer Pad (incl. w/25) (1)
*(NOTE: Part Number 34259A requires retainer 80201A)
NOTE: uindicates a change has taken place
since last publication of this manual
Ref # Part No. Description Qty
28 50836A Retainer 1
29 962968 Screw 4
30 63930A Belt Guard 1
31 57370A Base, Retainer (incl. w#25) (1)
32 980681 Washer, Wave 2
33 39857A Wheel 2
34 920346 Palnut 2
35 85383A Screw, 10-32 x
3
/4 7
36u 30285A Handle, Front 1
37 50820A Spring, Extension 2
38 50798A Lever, Switch 2
39 50780A Handle, Rear 1
40 920722 Nut, 10-32 ESNA 7
41 962957 Screw 2
42 50821A Spring, Compression 1
43 50799A Interlock, Main 1
44 50806A Button, Interlock 1
45 40109A Switch 2
46 41956A Cord 1
47 747553 Strain Relief 1
48 66542A Pin 1
49 69124B Handle Tube 1
50 64325A Cord Hook 1
51 930005 Rivet 2
52 10083A Cord, Power Supply 1
53 85381A Screw 1
54 35703A Bumper 1
55 170686 Locknut 1
56u 70651A Label, Div. of ALTO 2
57 30185A Baffle 1
58 60493A Carrier, Bearing 1
59 10283A Spindle Asm.
(includes 18, 19, 22, 58) 1
60 915085 Key 1
61 70448A Label, Frame US 1700 1
Clarke
®
Operator's Manual - Ultra Speed Burnisher 1700 Page -15 -
