Clarke Alto User Manual

Clarke
®
Image Mini Spot
Solution Tank Parts List
12/02
Clarke
®
Operator's Manual - Image Mini Spot Page 5-4
Ref. Part No. Description Qty
1 52887A Tank, Spotter Sol. 1
2 52888A Hosebarb, 1/8 NPT x 3/8 90D Plastic 3
3 52889A Nipple, 1/8 FPT QD Male Brass 1
4 52890A Nipple, 1/8 Close 1
5 52891A Clamp, 3/8 Hose (D-Slot) 5
6 52892A Hose, 3/8" Nylon Braid x 10" 1
7 52893A Strainer, 3/8 NPT 60 Mesh 1
8 52894A Hosebarb, 1/8 MPT x 3/8 Plastic 2
9 52895A Hosebarb, 3/8 MPT x 3/8 90D 1
10 52896A Hose, 3/8" Rubber x 17" 1
11 52897A Nut, 10-32 w/Star Washer Pltd. 5
12 52898A Bracket, PVC Flojet Pump L-Shape 2
13 52899A Pump, 110/120 60Hz Flojet 1
14 52961A Hose, 3/8" Rubber x 11" 1
15 52962A Plate, Lower Panel Cover 1
16 52963A Washer, #10 Lock Ext. Star 1
17 52964A Screw, 10-32 x 1/2 PPHMS SS NP 5
18 52965A Screw, 10-32 x 3/8 PPHMS SS NP 13
19 52966A Plate, Vac Motor 1
20 52967A Vac. Asm. 115V Spotter 1
21 52968A Switch, SPST 2 Positon Rocker 1
22 52969A Screw, 10-32 x 3/8 HHTR w/Star 4
23 52970A Cord, 25' 18/3 1
24 52971A Strain Relief, 1/2 NPT Trumpet 1
25 52972A Rivet, 1/8 OD x 3/8 Grip 2
26 52973A Keeper, Tension Latch 1
27 52974A Screw, 10-32 x 1 PPHMS GRN 1
28 52975A Plate, Switch/Cord Spotter 1
29 52976A Nut, 1/2 Conduit 1

Clarke Alto Specifications

General

Brand	Clarke
Model	Alto
Category	Vacuum Cleaner
Language	English
