Clarke
®
Image Mini Spot
Cart and Parts List
12/02
Page 5-7 Clarke
®
Operator's Manual -Image Mini Spot
1
2
3
4
5
6
7
8
Ref. Part No. Description Qty
1 61690A Handle Weldment, Cart 1
2 85520A Screw, 8-00 x 1/2 Pan Head 2
3 59951A Wheel, 8" 2
4 920346 Palnut 2
5 50007A Bumper, Recessed 1
6 81110A Nut Hex, Elastic Lock, 10-24 1
7 61689A Chassis Weldment, Cart 1
8 962862 Screw, 10-24 x 1/2 PN ST 1
Kit 11678A Cart (entire asm. as kit) 1
