CONTENTS
Ensure the bandsaw and its components suffered no damage during transit
and that all components are present. Should any loss or damage be
apparent, please contact your CLARKE dealer immediately.
The following components are supplied with the bandsaw assembly.
Item Description Qty Item Description Qty
1 Bandsaw Assembly 1 7 Push Stick 1
2 Tool (wrench) Set 1 8 Table with Insert 1
3 Guide Rail Fixing Knobs 4 9 Long Braces 2
4 Mitre Gauge Assembly 1 10 Legs 4
5 Guide Rail 1 11 Push Stick Hook 1
6 Rip Fence 1 12 Short Braces 2
Fastenings kit containing:
Socket Head Bolts M8 x 12 12 6 mm Flat Washer 8
8 mm Flat Washers 12 M6 Nut 8
M6 x 12 Coach Bolts 8 M4 x 10 Screws 2
1
3
2
4
6
9
8
5
7
10
12
11
