Clarke Clean Track 12 User Manual

06-2
5
Clean Track
®
12
FORM NO. 56041658
BASE SYSTEM
Item Ref. No. Qty Description
1 56265393 2 Bushing .31 x .50 x 1.18
2 56264382 1 Adaptor, Barbed
3 56002082 1 Pin, Spr .19 x 1.00
4 56002836 2 Nut, Hex Nyl Loc SS 10-24
5 56002938 2 Wsh, Flt SAE SS 5/16
6 56003272 1 Nut, Hex Jam SS 5/8-11
7 56003333 2 Scr, Hex SS 5/16-18 x 1.75
8 56003545 2 Scr, Pan Phil Plastite 8-10 x .75
9 56003611 2 Scr, Pan Phil SS 10-24 x .88
10 56003711 7 Scr, Pan Phil SS Plastite 10-14 x .62
11 56009205 2 Wsh, Flt SS .219 x .500 x .047/.062
12 56050955 1 Grommet
13 56219932 2 Clamp, Hose SAE #6
14 56260071 1 Terminal Block
15 56265051 1 Pump 115V
56265218 1 Pump Rebuild Kit (for use in 56265051)
16 56265103 1 Rectifi er, 35 Amp
17 56265342 1 Base Panel
18 56265343 1 Valve, Nozzle Assembly (items 29-36)
19 56265358 1 Base, 12
20 56265367 1 Gasket, Base Panel
21 56265373 1 Hose, 1/4 x 21.00L
22 56265377 1 Hook, Base
23 56756364 2 Clamp, Hose SAE #4
24 56265245 1 Hose
25# 56109565 1 Barb, Adapter 1/2 x 3/8NPT
26 56265323 1 Muffl er Set
27 56265399 4 Grommet
28 56369632 1 Elbow, 90 Street
29 56265219 1 Nipple, 1/4NPT x .88/1.12
30 56249342 1 Hose, Solution
31 56265037 1 Valve, Solenoid 115V
32 56265388 1 Elbow, Panel Mount
33 56265390 1 Nozzle
34 56369632 1 Elbow, 90 Street
35 56470138 1 Barb, 90 Elbow 1/4 x 1/4NPT
36 56756364 2 Clamp, Hose SAE #4
37 56265246 1 Spring, Comp .42 x 3.00 SS
# = Revised or new since last update
08-10

Clarke Clean Track 12 Specifications

General

Brand	Clarke
Model	Clean Track 12
Category	Floor Machine
Language	English
