Clarke Clean Track 12 User Manual

DECAL SYSTEM
06-2
7
Clean Track
®
12
FORM NO. 56041658
Item Ref. No. Qty Description
1 56265204 1 Bearing/Spindle Kit
NA 1 Spindle, Drive
NA 1 Washer, Bearing
NA 1 Bearing, Block
NA 1 Sheave Poly-V 6J17
NA 1 Bearing, Ball
NA 1 Bearing, Ball
2 56265344 1 Bracket, Motor Tension
3 56265340 1 Brush Assembly 12
4 56265077 1 Motor, 115V, 1/4 HP
5 56265370 1 Sheave, Poly-V
6 56265043 1 Clip, Brush Retainer
7 56002836 1 Nut, Hex Nyl Loc SS 10-24
8 56002894 1 Scr, Pan Phil SS 10-24 x .75
9 56003053 2 Nut, Hex Nyl Loc-Thin 10-32
10 56003424 2 Scr, Soc SS M6-1 x 20mm
11 56003426 2 Nut, Hex Nyl Loc SS M6-1
12 56009060 2 Wsh, Flt SS .260 x 1.000 x .074
13 56009131 2 Scr, Soc Set Loc 5/16-18 x .31
14 56249040 1 Belt, Poly V
BRUSH SYSTEM
