Clarke FG3005 User Manual

23
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
PARTS LIST
NO DESCRIPTION PAR T N O
1 UP170-41 Engine RKFG300501
2 Frame RKFG300502
3 Fuel Tank RKFG300503
4 Φ4.5
mm Fuel Pipe RKFG300504
5 Φ8 C
lamp RKFG300505
6 Φ7 C
lamp RKFG300506
7 Fuel Tank Filter RKFG300507
8 Fuel Switch RKFG300508
9 Fuel Tank Cap RKFG300509
10 Shock Absorption RKFG300510
11 Fuel Marker Assembly RKFG300511
12 Control Pannel RKFG300512
13 Alternator Guard Board RKFG300513
14 190 Front End Cover RKFG300514
15 190 Rear End Cover
Guar
d
RKFG300515
16 190 Rear End Cover RKFG300516
17 Wire Fasten Connection RKFG300517
18 AVR RKFG300518
19 Muffler RKFG300519
20 Mufler Gasket RKFG300520
21 Shock Absorption RKFG300521
22 Grounding Wire RKFG300522
23 Muffler Side Guard RKFG300523
24 Muffler Outside Guard RKFG300524
25 Rotor RKFG300525
26 Stator RKFG300526
27 Carbon Brush RKFG300527
28 Flange Bolt M5x12 RKFG300528
29 Flange Bolt M5x16 RKFG300529
30 Flange Bolt M6x12 RKFG300530
31 Flange Bolt M6x14 RKFG300531
32 Bolt M6x130 RKFG300532
33 Flange Bolt M8x20 RKFG300533
34 Bolt M8x25 RKFG300534
35 Bolt 5/16-210 RKFG300535
36 Full-thread Bolt M5x20 RKFG300536
37 Nut M5 RKFG300537
38 Flange Nut M6 RKFG300538
39 Flange Nut M8 RKFG300539
40 Flat Washer Φ5 RKFG300540
41 Flat Washer Φ6 RKFG300541
42 Flat Washer Φ8 RKFG300542
43 Spring Washer Φ5 RKFG300543
44 Spring Washer Φ6 RKFG300544
45 Spring Washer Φ8 RKFG300545
46 External Tooth Lock
Wa
sher Φ5
RKFG300546
47 External Tooth Lock
Wa
sher Φ6
RKFG300547
48 Flat Washer Φ8 RKFG300548
49 Large Flat Washer
Φ8(
H=3)
RKFG300549
50 Screw M6x12 RKFG300550
NO DESCRIPTION PART NO
