ASSEMBLY
1. Remove all items from the carton.
• The following items should be supplied. If any parts are missing or
damaged, please see your Clarke dealer.
ATTACH THE HANDLE
1. Push the upper handle onto the pins as shown until it clicks into place.
2. Fit the lance holder and cable holder as shown below using the fixing
screws supplied.
1 x High Pressure Cleaner 1 x Gun Assembly
1 x Upper Handle Assembly 1 x Lance & Nozzle Assembly
1 x Lance Holder and 2 Fixing Screws 1 x Detergent Bottle
1 x Cable Holder and 2 Fixing Screws 1 x Hose Adaptor and Water Inlet Flter
1 x High Pressure Hose (8 metre) 1 x Nozzle Clearing Pin
