PAR
TS IDENTIFICA
TION
1
8
9
10
11
12
13
7
1
Motor housing
2
On/Off switch (red button)
3
Main reservoir pressur
e gauge
4
Pressure regulator
5
Regulator locking ring
6
Output pressure gauge
7
T
rolley handle
8
Support foot
9
Drain valve
10
Compressed air reservoir
11
T
ransportation wheel
12
Data plate
13
Pressure regulator and cut-out
14
Outlet tap
2
4
3
6
5
14
10
12
Table of Contents
Air Compressor
1
Specifications
2
Table of Contents
3
Safety Precautions
4
Warning Symbols
9
Electrical Connections
10
Parts Identification
11
Assembly
12
Preperation for Use
14
Operating Instructions
15
Reset Button
17
Routine Maintenance
19
Troubleshooting
21
Specifications
22
Parts Diagram
24
Parts List
25
Declaration of Conformity
26
