12
ASSEMBLY
WARNING!
Before assembling and using the air compressor, make sure that you have
read and understood all of the safety instructions.
Installation
Take care when lifting the compressor from the packaging.
CAUTION! Do not lift the compressor by the pressure regulator and cut-out. Get
assistance if necessary. This unit weighs 21 kg.
After removing the compressor from its packaging, check the integrity of the
unit, making sure it has not been damaged in transit.
Fitting the transportation wheels
Fit the transportation wheels to either side of the compressor as shown in figures
1 & 2 using a 17mm spanner.
Figure 1
Figure 2
Bolt
Wheel
Washer
Spring
washer
Nut
