16
5 The illustration below shows the pressure regulator locked at 6 bar.
• Never set the pressure higher than the rated pressure of the attachments
being used, as there is a risk of bursting and resultant injury.
To increase the output pressure from this preset value you will need to
intentionally loosen the locking ring.
• Only alter this setting if you are using an air tool with a higher pressure
requirement.
6 Open the outlet tap.
OPERATING INSTRUCTIONS
Pressure regulator
Regulator locking ring
locked at desired
pressure.
Output pressure gauge
Main
Reservoir
pressure
gauge
Figure 8
Outlet
tap
