User Guide| Eclipse HX-Median
Page 109
9 IVC-32 card for IP-based connections
The IVC-32 (Instant Voice Communication) interface card provides the
Eclipse HX-Median with connectivity over IP to V-Series IP panels and
Concert servers.
Each IVC-32 interface card comprises:
 A front card with a reset button and various status indicators (including
status LEDs for power, port activity and LAN status).
Note: The port activity LEDs are not active on the IVC-32 front card as
the E1/T1 ports are not used.
 A rear card with eleven RJ-45 ports giving eight E1/T1 ports (not used),
DECT sync in and out (not used) and a LAN port used for the IP
connection.
Note: An Ethernet cable must be connected to the IVC-32 interface LAN port for the
card to function correctly.
Note: For an overview of the Eclipse HX-Median, see 3 Overview.
