Table 22: Key to IVC-32 rear panel connectors
Note: The E1/T1 and DECT ports are not used on the IVC-32 interface and should
not be connected.
9.3 IVC-32 interface applications
The IVC-32 interface may be used to connect:
V-Series IP panels to an Eclipse matrix.
Provide a link to a Concert Instant Voice Router (IV-R) server.
9.3.1 V-Series IP Panels
V-Series panels with V5.1 or later software may be enabled to communicate with
an Eclipse HX-Median matrix over an IP network using the IVC-32 interface card.
The advantage of using IP communication is that it enables remote panels to
communicate over an existing local (LAN) or wide area (WAN) network rather
than requiring a dedicated link.
9.3.2 Concert Users
The IVC-32 interface will allow Concert users to establish audio links with users
on the Eclipse matrix via the Concert IV-R server.
This server will provide a link over IP between Concert users and the Eclipse
matrix. Concert users cannot connect directly to the IVC-32 interface card.
Concert users communicate with Eclipse users using a soft-panel, rather than
the main Concert Client application.
This soft panel is configured using the EHX configuration software and the
configuration information is uploaded to the Concert user’s soft-panel on
connection to the matrix.
