User Guide| Eclipse HX-Median
Page 95
Figure 7-5: Example fiber-optic connection setup
TX2- E-FIB
card#1 - RX2
TX2- E-FIB
card#1 - RX2
TX2- E-FIB
card#1 - RX2
TX2- E-FIB
card#1 - RX2
TX2- E-FIB
card#1 - RX2
TX1- E-FIB
card#1 - RX1
TX1- E-FIB
card#1 - RX1
TX1- E-FIB
card#1 - RX1
TX1- E-FIB
card#1 - RX1
TX1- E-FIB
card#1 - RX1
System #1 System #2 System #3
System #4System #5
Primary ring
Secondary ring
