Clear-Com TEMPEST 2400 Quick Start Guide

What’s in the box:
BaseStation
● CM-222 series BaseStation
● Power cord
● 2dBi Omni-directional whip antenna
● 3.5mm to 3.5mm 3 conductor data pairing cable
» Used to pair a BaseStation to the BeltStation(s)
● USB-A to USB-B cable
» Used to update BaseStation rmware
● USB-A to Mini-USB
» Used to update BeltStation rmware
● BaseSync cable
» Used if you have more than one BaseStation
» Improves RF performance when using multiple systems
● CD with manual, T-Desk software
BeltStation
● CP-222 series BeltStation
● Li-Poly rechargeable battery
● 5VDC wall charger with Mini-USB connector
Remote Transceiver (optional)
● Remote RF transceiver (CCT-RT)
● RJ-45 to RJ-45 CAT-5 cable
● 2dBi Omni-directional whip antenna (x2)
● Mounting plate and screws
Directional Antenna Kit (optional)
● Directional antennas (CCT-DAKIT1) (x2)
● Mounting brackets (x2)
● Antenna mounting bar
● “C” clamp mount
● “RP-TNC” to “N” cables (x2)
What else you may need
● Headset, one for each user
» May be dynamic or electret microphone, with a 4-PIN
XLR female connector
● 3-PIN XLR cables to connect to external 2-Wire Intercom
system
● RJ-45 cables to connect to external 4-Wire Intercom
system
● RJ-45 cable to connect to PC for T-Desk LAN control
5 Bay Battery Charger (optional)
● Battery charger
● AC cable
Note: Charge ALL BeltStation batteries prior to set-up.
Tempest
®
2400
399G078 Rev A 15 July-2014
2-Channel Quick Start Guide
