User manual
Made in Germany Page 11
2.8
If the
Performance DC
turntable was purchased as a package together with the
Clarify
tonearm,
please follow the below described installation of the tonearm.
Position of the screw
to fasten the
tonearm with 2mm
allen key
Boring for the
tonearm
feet
1. Insert carefully rst the cable and then the tonearm feet through the hole of the tonearm base.
2. Now adjust the tonearm height.
3. At the end secure the tonearm with the screws with are already integrated at the front of the
mounting base.
4. For tonearm and cartridge mounting please refer to the user manual of the respective
manufacturer.
Pic. 10: Rear view
Clarify
tonearm
