Clearaudio Tracer - Mounting the Tracer Tonearm

User manual / Bedienungsanleitung
Made in Germany Page / Seite 9
3. Mounting the Tracer tonearm without VTA-Lifter
Take the clamping ring and place it on the recess
in the tonearm base.
Now you can attach the clamping ring to the
tonearm base with the 3 supplied M4 x 10
screws. Make sure that the side hole of the
clamping ring (see Pic. 9) remains accessible.
Insert the tonearm cable rst and then the
tonearm foot of the
Tracer tonearm into the hole
of the clamping ring.
Now x the tonearm, do not over-tighten, so
that you can nally adjust it later!
To assemble the Tracer tonearm with VTA-Lifter,
please follow the separate user manual for the
VTA-Lifter.
Pic. 9: Mounting the tonearm
Pic. 8: Mounting the clamping ring
