ClearFox®Control Unit CU-M
15
9.4.2 Selectable output assignment
FUNCTION/
SELECTABLE OPTION
AND CONSEQUENCE
FILLING
(ON DAY/OFF DAY //
ON NIGHT/OFF
NIGHT // ON
HOLIDAY / OFF
HOLIDAY)
Pump
Out 2
Current limits for pump
(300/1800mA) applied
Airlift
Out 1 + 2
Current limits for Blower
(250/900mA)+ valve (50/150mA)
applied
Generic pressure limits
(7/350mbar) for Blower applied
AERATION
(ON DAY/OFF DAY //
ON NIGHT/OFF
NIGHT // ON
HOLIDAY / OFF
HOLIDAY)
Blower (+ valve)
Out 1 (+ 5)
Current limits for Blower
(250/900mA)+ valve (50/150mA)
applied
Generic pressure limits
(7/350mbar) for Blower applied
SLUDGE
(ON DAY/OFF DAY //
ON NIGHT/OFF
NIGHT // ON
HOLIDAY / OFF
HOLIDAY)
Blower + valve
Out 1 + 4
Current limits for Blower
(250/900mA)+ valve (50/150mA)
applied
Generic pressure limits
(7/350mbar) for Blower applied
Via sludge pump (Out 4)
Current limits for pump
(300/1800mA) applied
CLEARWATER
(ON DAY/OFF DAY //
ON NIGHT/OFF
NIGHT // ON
HOLIDAY / OFF
HOLIDAY)
Blower + valve
Out 1 + 3
Current limits for Blower
(250/900mA)+ valve (50/150mA)
applied
Generic pressure limits
(7/350mbar) for Blower applied
Pump
Out 3
Current limits for pump
(300/1800mA) applied
10 MENU
PPU used its “standard menu” for the sample.
PPU assumes, that the menu is mostly self-explaining. For questions, please do not hesitate to
contact us via info@clearfox.com.
11 INTERNAL WEBPAGES
PPU used its “standard webpages” for the sample.
PPU assumes, that the webpages are mostly self-explaining. For questions, please do not
hesitate to contact us via info@clearfox.com.
12 TRANSFERRING THE ASW / FW / WEB-PAGES
The ASW, FW and the web pages can be transferred by USB or Wi-Fi.
