ClearFox®Control Unit CU-M
4
2 MOST IMPORTANT INFORMATION
2.1 SWITCHING THE DEVICE OFF
The ClearFox®Control Unit CU-M must not be switched off by disconnecting mains and
batteries. As it works with an operating system and Flash memory, it must be shut down
properly.
Shutting down must be done by pressing the OK button for > 10s. On the LCD a message will
appear. Now the mains connection can be disconnected. That’s it.
2.2 FIRST START
Please mind, that after the first start the plant type must be selected, as the demo software
contains different plant types.
The ClearFox®Control Unit CU-M will restart then, which will take some 2-3min.
2.3 LOGIN SERVICE MENU
The Service PIN is 1111.
2.4 CONNECTING VIA WI-FI / INTERNAL WEBPAGES
- SSID: WWTP-Controller
- Wi-Fi password: 12345678
- IP address (must be entered into the browser address line (=where you’d type
www.google.com): http://192.168.117.1/
o Username for service login: service
o Password: 1111 (same as service menu PIN)
3 INTRODUCTION
The ClearFox®Control Unit CU-M platform is a powerful, free programmable control unit for
decentralized STP.
The IoT platform is equipped with a Wi-Fi module (access point (AP) and station mode (ST), even
parallel) and an integrated webserver. Thus, the Sequetrol® IoT can be either operated via the
LCD + menu or via any web browser (smartphone, tablet, PC). An internet connection is not
required. The Wi-Fi of the control unit creates a local hotspot (in access point mode).
More information about the IoT platform can be found on our webpages.
4 SWITCHING THE DEVICE OFF
The ClearFox®Control Unit CU-M must not be switched off by disconnecting mains and
batteries. As it works with an operating system and Flash memory, it must be shut down
properly.
Shutting down must be done by pressing the OK button for > 10s. On the LCD a message will
appear. Now the mains connection can be disconnected. That’s it.
