CleaverBrooks FLX Series User Manual

750-177 8-3
Part List, Hot Water 250 350 500 800 1100
ITEM DESCRIPTION PART #
REQ
PART # REQ PART # REQ PART # REQ PART # REQ
1. Base 315-1124 1 315-1169 1 315-1180 1 315-1194 1 315-1203 1
2. Roof 315-1127 1 315-1167 1 315-1178 1 315-1192 1 315-1202 1
3.a Front wall, w/o Hinge 315-1262 1 315-1265 1 n/a n/a n/a
3.b Front wall w Hinge 315-1128 1 315-1166 1 315-1177 1 315-1191 1 315-1201 1
4.
Rear wall-large piece 315-1129 1 315-1165 1 315-1176 1 315-1190 1 315-1190 1
5.
Outer casing panel 315-1130 6 315-1164 6 315-1175 8 315-1189 10 315-1198 12
6.
Outer casing strips-top 315-1131 2 315-1163 2 315-1174 2 315-1188 2 315-1197 4
7.
Plate, base to wall 315-1132 4 315-1132 4 315-1132 4 315-1132 4 315-1132 4
8.
Outer casing strips corner strip 315-1133 4 315-1162 4 315-1173 4 315-1187 4 315-1187 4
9.
Burner plate Note 5 1 Note 5 1 Note 5 1 Note 5 1 Note 5 1
10.
Inner side panel Left Hand 315-1135 2 315-1161 2 315-1172 2 315-1186 2 315-1196 2
11.
Inner side panel Right Hand 315-1136 2 315-1160 2 315-1171 2 315-1185 2 315-1195 2
12.
Mounting Plate 315-1143 1 315-1143 1 315-1143 1 315-1143 1 315-1143 1
13.
Plate, Collar, Lower Outer 315-694 2 315-694 2 315-695 2 315-695 2 315-695 2
14.
Plate, Collar, Upper Outer 315-1159 2 315-1159 2 315-1183 2 315-1183 4 315-1210 2
15.
Plate, Cover, Lug, Lifting 315-1100 1 315-1100 1 315-1100 1 315-1099 1 315-1099 1
16.
Cap, sight 550-42 1 550-42 1 550-42 1 550-42 1 550-42 1
17.
Capscrew, hex hd. 3/8”-16x 3/4”lg 868-1506 26 868-1506 28 868-1506 60 868-1506 96 868-1506 128
18.
Capscrew, hex hd. 1/2”-13x 1-1/2”lg 868-102 8 868-102 8 868-102 8 868-102 8 868-102 8
19.
Capscrew, hex hd. 5/8”-11x 1-1/2”lg 868-188 8 868-188 8 868-188 8 868-188 8 868-188 8
20.
Screw, self tapping, ¼” x 1”lg 841-423 50 841-423 50 841-423 50 841-423 50 841-423 54
21.
Locknut, hex hd., 3/8” 869-510 118 869-510 124 869-510 180 869-510 232 869-510 284
22.
Nut, hex hd., ½” brass 869-27 12 869-27 12 869-27 12 869-27 12 869-27 12
23.
Nut, hex hd., ½” 869-144 24 869-144 24 869-144 24 869-144 28 869-144 28
24.
Capscrew, Hex hd ¾”-10 x 6” LG 868-600 2 868-600 2 868-600 2 868-600 2 868-600 2
25.
Washer, flat, ½” 952-286 44 952-286 44 952-286 44 952-286 48 952-286 48
26.
Washer, flat, 5/8” 952-321 8 952-321 8 952-321 8 952-321 8 952-321 8
27.
Never-Seez 797-1816 1 797-1816 1 797-1816 1 797-1816 1 797-1816 1
28.
Inner Casing Spacer Block 315-1336 8 315-1336 8 315-1336 12 315-1336 16 315-1336 20
29.
Inner Side Panel Mid Left n/a n/a n/a 315-1294 2 315-1294 2
30.
Inner Side Panel Mid Right n/a n/a n/a 315-1208 2 315-1208 2
31.
Inner Side Panel Mid n/a n/a 315-1206 2 n/a 315-1209 2
32.
Retaining Plates, Lower, Inner, Small 315-1178 3 315-1178 3 315-1280 3 315-1280 3 315-1280 3
33.
Retaining Plates, Lower, Inner, Large 315-1158 1 315-1158 1 315-1182 1 315-1182 1 315-1182 1
34.
Plate, collar, upper, inner 315-1204 2 315-1204 2 315-1207 2 n/a 315-1183 2
35.
Assembly, rear wall corner piece 315-1140 1 315-1279 1 315-1281 1 315-1282 1 315-1282 1
36.
Gasket, Expanded PTFE 3/8” x 3/16” 32-2560 70 ft 32-2560 75 ft 32-2560 99 ft 32-2560 127ft 32-2560 149ft
37.
Handle, Flush Mount, Snap In 865-68 12 865-68 12 865-68 16 865-68 16 865-68 24
