CleaverBrooks FLX Series User Manual

Chapter 2 Profire V Burner
2-32 750-177
Figure 2-20: Drawer Assembly for (VLG) Gas/Oil (V35-55) - Watertube
.16" REAR FACE
OF DIFFUSER TO
FRONT FACE OF
AIR BAFFLE
656 10214 000
Figure 2-21: Drawer Assembly for (VG) Gas Only (V60-110) - Watertube
1.83" REAR FACE
OF DIFFUSER TO
FRONT FACE OF
AIR BAFFLE
.00" FROM
NOZZLE TIP
TO FRONT FACE
OF DIFFUSER
656-10215-000
Figure 2-22: Drawer Assembly for (VLG) Gas/Oil (V60-110) - Watertube
