9028-BC
START-UP / SERVICE REPORT
Test Conducted
GAS OIL
Low 50% High Low 50% High
Firing Rate MMBtu / gph
Stack Temp (Gross)
o
F
Room Temp
o
F
O2%
CO2%
CO (PPM)
NOx (PPM)
Smoke (Bacharach)
Combustion Eff.%
Stack Draft "W.C.
Furnace Pressure "W.C.
Blast tube Pressure "W.C.
Steam Pressure PSIG
Water Temperature
o
F
Supply oil pressure PSIG
Return oil pressure PSIG
Vacuum oil pump "HG
Oil Temperature
Atom. air pressure
Gas Pressure @ Burner Inner Manifold
Manifold "W.C. Outer Manifold
Center Gas pressure "W.C.
Gas Pressure @ Regulator Inlet PSIG
Gas Pressure @ Regulator Outlet PSIG
Pilot Gas Pressure @ Regulator Outlet "W.C.
Flame Signal Main Low 50% High
Control Checks Test Set Point
Low Water Cut Off
Aux. LWCO
High Water Cut Off
Operating Limit
High Limit
Operating Control
Stack Temp Interlock
Flame Failure
Combustion Air Switch
High Purge Switch
Low Fire Interlock
Oil Pressure Switch
Oil Valve with P.O.C.
Interlock
High Gas Pressure
Switch
Low Gas Pressure
Switch
Gas Valve P.O.C.
Interlock
Pilot Turndown Test
Flame Signal Pilot
(For Low NOx Burners)
Blast Tube Temp.
Interlock
FGR Line Purge Switch
FGR Valve P.O.C.
Switch
Voltage Amperage
Electric Motors L1 L2 L3 L1 L2 L3
Control Voltage
Blower Motor
Air Compressor
Air-Oil or Metering
Adjusted by:
Date:
Accepted by:
(Signature Required)
The following information should be filled in by the service technician at start-up or after any adjustment to the burner.
A copy of the start-up report MUST be returned to CB in order to validate the warranty of the burner.
Burner Model Serial Number Start-up Date
To Next Page
