Prometha™ Installation
750-441
28
49 Recycle Limit Relay BI
50 External Device Start BI
51 Non Recycle Limit Relay BI
52 Drive to Lo Fire (FARC) BI
53 Start Slave Blr (2 Blr LL) BI
54 Load Demand Output BI
55 Alm Output BI
56 Boiler Ready (LL) BI
57 Boiler Load Demand BI
58 Firing Rate Rem/Llag BI
59 Firing Rate Manual BI
60 Firing Rate Auto BI
61 Hot Stand By BI
62 Warm Up BI
63 Fuel 3 Selected BI
64 Aux Alm 3 BI
65 Steam or Hot Water 1 = Steam BI
66 Level Master Present BI
67 Variable Speed Drive Present BI
68 Economizer Present BI
69 Combustion Air Temp Present BI
70 Economizer Inlet FW Sensor Present BI
71 O2 Analyzer Present BI
72 Feedwater or Return Temp Present BI
73 Outdoor Reset Selected BI
74 Parallel Posing Selected BI
75 Two Boiler Lead Lag Master Select BI
76 Two Boiler Lead Lag Slave Select BI
77 Master Panel Select BI
78 Hot Stand By Select BI
79 Dual Setpoint Select BI
80 Slot 8 Ch 0 AI Selected BI
81 Slot 8 Ch 1 AI Selected BI
82 Slot 8 Ch 2 AI Selected BI
83 Slot 8 Ch 3 AI Selected BI
84 Honeywell or Fireye 1 = Fireye BI
85 Hi Water Alm BI
86 Oil Actuator Out Of Pos Alm BI
87 FGR Actuator Out Of Pos Alm BI
88 Air Actuator Feedback Fail Lo Alm BI
89 Air Actuator Feedback Fail Hi Alm BI
90 NG Actuator Feedback Fail Lo Alm BI
91 NG Actuator Feedback Fail Hi Alm BI
92 Oil Actuator Feedback Fail Lo Alm BI
93 Oil Actuator Feedback Fail Hi Alm BI
94 FGR Actuator Feedback Fail Lo Alm BI
95 FGR Actuator Feedback Fail Hi Alm BI
96 VSD Deviation Alm BI
97 Increase MSG Reg Size Bit (CB Only) BI
98 Air/Fuel Deviation Alm BI
99 2nd Stage CEC Economizer Selected BI
Hawk 4000 V2 (continued)
