Apex Tool Group P2543BA | 2021-01 11
1
EN
Rapid Charger 18 V
Depending on the mode used do the following:
Working with controller (mPro mode)
Configure the tool, refer to the Programming Manual –
CTBP & CTBA.
Configure WLAN on the controller, refer to the Quick
Installation Guide – CTBP & CTBA Data Transmission
and the Programming Manual mPro(...)GCD.
Stand-alone (FastApps mode)
Configure the tool, refer to the Programming Manual –
CTBP & CTBA.
7 Maintenance
Implement a comprehensive safety maintenance program
to provide regular inspection for all phases of tool operation
and power supply.
8 Performance data
Pistol
Right Angle
Order no. Country
T50-1000499 North America
1-Bay
T50-1000506 Europe
T50-1000507 Brazil
T50-1000543 Argentina
T50-1000544 United Kingdom
T50-1000545 China
T50-1000546 Japan
T50-1000500 North America
6-Bay
T50-1000508 Europe
T50-1000547 United Kingdom
After … cycles
a.
)
a. Use of 80% of maximum torque
Measures
Daily Check connections.
Check all external tool compo-
nents.
Check the tool for excessive
vibration or unusual noise.
500,000 Send tool to a certified Sales &
Service Center for evaluation.
Model no. Torque Range
Nm
Torque Range
ft-lb
Nominal
Power
Speed Weight
a.
Length Side to Center Height
a.
Output
Min Max Min Max W r/min kg lb mm in mm in mm in
CTBPW05Q 1.1 4.9 0.8 3.6
225
3525 0.90 2.00 191 7.52 19.3 0.76 210.0 8.27 1/4“
CTBPW10Q 2.4 10.0 1.8 7.4 1600 0.95 2.10 207 8.15 19.3 0.76 210.0 8.27 1/4“
CTBPW15Q 3.4 14.4 2.5 10.6 1125 0.95 2.10 207 8.15 19.3 0.76 210.0 8.27 1/4“
a. Value does not include battery pack. Weight of battery pack T50-1000497: 0.43 kg/.94 lb, T50-1000498: 0.72 kg/1.60 lb
Model no. Torque Range
Nm
Torque Range
ft-lb
Nominal
Power
Speed Weight
a.
Length
a.
Side to Center Height Output
Min Max Min Max W r/min kg lb mm in mm in mm in
CTBAW153 3.6 15.0 2.7 11.1
225
1025 1.40 3.10 515 20.28 14.3 0.56 38.7 1.52 3/8“
CTBAW213 5.2 21.0 3.8 15.5 735 1.40 3.10 515 20.28 14.3 0.56 38.7 1.52 3/8“
CTBAW273 6.8 27.0 5.0 19.9 560 1.40 3.10 515 20.28 14.3 0.56 38.7 1.52 3/8“
CTBAW383 10.0 38.0 7.4 28.0 395 1.55 3.40 525 20.60 16.5 0.65 44.5 1.75 3/8“
CTBAW503 13.0 50.0 9.6 36.9 285 1.60 3.50 534 21.02 17.0 0.67 43.8 1.75 3/8“
CTBAW653 17.0 65.0 12.5 47.9 220 1.70 3.70 543 21.38 19.0 0.75 46.8 1.84 3/8“
a. Value does not include battery pack. Weight of battery pack T50-1000497: 0.43 kg/.94 lb, T50-1000498: 0.72 kg/1.60 lb
