Clevo ITAUTEC W244HUQ Series User Manual

Disassembly
Removing the Keyboard 2 - 17
2.Disassembly
Removing the Keyboard
1. Turn off the computer, and remove the battery (page 2 - 5),and the component bay cover (page 2 - 8)
2. Remove screws
- from the bottom of the computer and use the Eject Pin Tool to carefully push out the key-
board at point
3. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable.
Figure 13
Keyboard Removal
a. Remove screws from the
bottom of the computer
and use the Eject Pin
Tool to push out the key-
board at point .
b.Carefully lift the keyboard
up.
3

4. Keyboard
•2 Screws
1
2
3
a.
c.
1
3
2
b.
4
