Figure 6 - Front, Left & Right Views
1. LED Indicator
2. DC-In Jack
3. HDMI-Out Port
4. USB 3.1 Gen 2 Type-A Port
5. DisplayPort 1.2 over USB 3.1 Gen 2 Type-C Port with Power
Delivery (DC-In)*
*This port allows you to use a third party AC/DC adapter/power bank
plugged into the port as a power supply. If you are using a power
bank make sure that it complies with the USB-C PD (Power Delivery)
standard specification (20V/65W - 20V/100W). If you are using a
third party AC/DC adapter, the rating of the adapter must be at least
20Volts, 3.25A (65 Watts) and it should be appropriately certified.
6. Speakers
7. Power Button
8. MicroSD Card Reader
9. 2-In-1 Audio Jack (Headphone and
Microphone)
10. USB 3.0 (USB 3.1 Gen 1) Type-A Port
11. Security Lock Slot
4
5
1
8
10
2
7
9
Front
Left
Right
3
6
6
11
