Clevo N240BU - Removing the 3 G Module

Disassembly
Removing the 3G Module 2 - 13
2.Disassembly
Removing the 3G Module
3G Module Removal Procedure
1. Turn off the computer, remove the battery (page 2 - 5).
2. Locate the module, it is visible at point
(Figure 7a).
3. Carefully disconnect the cables & , and then remove the screw from the module
(Figure 7b).
4. The module will pop-up
(Figure 7c).
5. Lift the module up and off the computer
(Figure 7d).
Figure 7
3G Module Removal
a. Locate the module.
b. Disconnect the cables and
remove the screw.
c. The module will pop-up.
d. Lift the module up off the
socket.
1
2
3
4
3
5
a.
b.
2
5
c.
3
4
5
d.
1

5. 3G Module
•1 Screw
