Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. CCD Connector
2. Connector
3. USB Board
Connector
4. USB Connector
5. Touchpad Cable
Connector
6. Fingerprint
Connector
7. Battery Connector
8. RTC Connector
9. Speaker Connector
10. LCD Connector
11
10
9
1
2
4
6
7
3
5
8
