Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 9
Mainboard Bottom
Connectors
1. Battery
Connector
2. CMOS Battery
Connector
3. Speaker Cable
Connector
4. CPU Fan Cable
Connector
5. RJ-45 LAN Jack
6. External Monitor
Port
7. DC-In Jack
8. LCD Cable
Connector
9. CCD Cable
Connector
1
2
4
5
6
7
8
9
3
