Clevo W170HN User Manual

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow (Figure 1a
).
3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a
).
4. Slide the battery in the direction of the arrow (Figure 1b
).

3. Battery
1
2
6
3
4
Figure 1
Battery Removal
a. Slide the latch and hold it
in place.
b. Slide the battery in the di-
rection of the arrow.
a.
b.
3
4
1
2
