14
English
3G Module
If you have included an optional 3G module in your purchase option, follow the instructions below to install the USIM
card (which will be provided by your service provider), and then run the appropriate application supplied with your
module.
USIM Card Insertion
1. Turn off the computer, and turn it over and remove the battery (slide the latches in the direction indicated below and slide the bat-
tery out).
2. Insert the USIM card as illustrated below until it clicks into position, and replace the battery.
Figure 7 - Remove the battery and Insert the USIM Card
Model A
USIM Card Orientation
Note that the USIM card’s
readable side (with the gold-
colored contacts) should
face upwards as illustrated.
1
1
