System Map: Front View with LCD Panel Open (Models A & B)
Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.
6
Figure 2
Front View with LCD
Panel Open (Models A
& B)
1. PC Camera
(Optional)
2. Built-In Microphone
3. LCD
4. Power Button
5. Keyboard
6. Touchpad & Buttons
2
4
1
6
3
5

Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmission devices aboard aircraft is usually prohibited.
Make sure the wireless modules are OFF if you are using the computer aboard aircraft.
Use the key combinations to toggle power to the 3G/WLAN/Bluetooth modules, and check the
LED indicator/visual indicator to see if the modules are powered on or not (see Table 2 on
page 7).
Model A
14” (35.56cm)
Model B
15.6” (39.62cm)
