Table 17c: Performance Data — Tranquility
®
30 Digital - Model - 049
Full Load - with vFlow
™
Performance capacities shown in thousands of Btuh Antifreeze use recommended in this range. Also Clip JW3 on DXM2 board.
EWT
°F
Cooling - EAT 80/67 °F Heating - EAT 70°F
GPM
WPD
CFM TC SC kW EER HR LWT HWC GPM
WPD
CFM HC kW COP HE LAT LWT HWC
PSI FT PSI FT
20
2.5 0.1 0.2 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 12.0 4.1 9.4 1450 31.4 3.17 2.9 20.9 90.1 16.5 3.3
2.5 0.1 0.2 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 12.0 4.1 9.4 1650 31.9 3.07 3.0 21.4 87.9 16.4 3.3
30
3.1 0.1 0.2 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 6.0 0.9 2.1 1450 34.7 3.16 3.2 24.2 92.2 21.9 3.4
3.1 0.1 0.2 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 6.0 0.9 2.1 1650 35.3 3.06 3.4 24.8 89.8 21.7 3.5
3.1 0.1 0.2 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 9.0 2.1 4.9 1450 36.2 3.16 3.4 25.7 93.1 24.3 3.5
3.1 0.1 0.2 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 9.0 2.1 4.9 1650 36.8 3.06 3.5 26.3 90.6 24.1 3.5
3.1 0.1 0.2 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 12.0 3.8 8.8 1450 37.1 3.16 3.4 26.5 93.7 25.6 3.5
3.1 0.1 0.2 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 12.0 3.8 8.8 1650 37.6 3.06 3.6 27.2 91.1 25.5 3.6
40
4.1 0.2 0.5 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 6.0 0.8 1.8 1450 39.9 3.18 3.7 29.2 95.5 30.3 3.6
4.2 0.2 0.5 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 6.0 0.8 1.8 1650 40.5 3.08 3.9 30.0 92.7 30.0 3.7
4.1 0.2 0.5 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 9.0 2.0 4.6 1450 41.7 3.21 3.8 30.9 96.6 33.1 3.7
4.2 0.2 0.5 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 9.0 2.0 4.6 1650 42.3 3.11 4.0 31.7 93.8 32.9 3.8
4.1 0.2 0.5 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 12.0 3.6 8.4 1450 42.7 3.22 3.9 31.8 97.3 34.7 3.8
4.2 0.2 0.5 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 12.0 3.6 8.4 1650 43.3 3.12 4.1 32.7 94.3 34.6 3.9
50
6.0 0.7 1.7 1360 54.0 33.2 2.29 23.6 61.7 70.6 2.3 6.0 0.7 1.7 1450 45.0 3.26 4.0 34.0 98.8 38.7 3.9
6.0 0.7 1.7 1550 54.9 35.7 2.37 23.2 63.0 71.0 2.3 6.0 0.7 1.7 1650 45.7 3.16 4.2 34.9 95.7 38.4 4.0
6.2 0.8 1.8 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 9.0 1.9 4.3 1450 47.2 3.30 4.2 36.0 100.1 42.0 4.1
6.3 0.8 1.9 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 9.0 1.9 4.3 1650 47.9 3.20 4.4 37.0 96.9 41.8 4.1
6.2 0.8 1.8 1360 54.0 33.1 2.26 23.9 61.6 70.0 2.3 12.0 3.5 8.0 1450 48.3 3.33 4.2 37.1 100.9 43.8 4.1
6.3 0.8 1.9 1550 54.9 35.6 2.34 23.5 62.9 70.0 2.3 12.0 3.5 8.0 1650 49.1 3.23 4.5 38.1 97.5 43.7 4.2
60
6.0 0.7 1.6 1360 53.1 33.6 2.52 21.1 61.6 80.5 2.9 6.0 0.7 1.6 1450 50.2 3.37 4.4 38.8 102.1 47.1 4.3
6.0 0.7 1.6 1550 54.0 36.1 2.61 20.7 62.9 81.0 2.9 6.0 0.7 1.6 1650 51.0 3.27 4.6 39.8 98.6 46.7 4.4
9.0 1.8 4.2 1360 53.9 33.4 2.35 22.9 61.8 73.7 2.4 9.0 1.8 4.2 1450 52.7 3.44 4.5 41.0 103.6 50.9 4.4
9.0 1.8 4.2 1550 54.8 36.0 2.44 22.5 63.1 74.0 2.5 9.0 1.8 4.2 1650 53.5 3.33 4.7 42.1 100.0 50.6 4.5
12.0 3.4 7.8 1360 54.0 33.1 2.27 23.8 61.6 70.3 2.3 12.0 3.4 7.8 1450 54.0 3.48 4.5 42.2 104.5 53.0 4.5
12.0 3.4 7.8 1550 54.9 35.6 2.35 23.4 63.0 70.5 2.3 12.0 3.4 7.8 1650 54.8 3.37 4.8 43.3 100.8 52.8 4.6
70
6.0 0.7 1.5 1360 51.0 33.0 2.78 18.3 60.4 90.1 3.6 6.0 0.7 1.5 1450 55.5 3.52 4.6 43.5 105.4 55.5 4.6
6.0 0.7 1.5 1550 51.9 35.5 2.88 18.0 61.7 90.6 3.7 6.0 0.7 1.5 1650 56.3 3.41 4.8 44.7 101.6 55.1 4.7
9.0 1.8 4.0 1360 52.6 33.5 2.60 20.2 61.3 83.6 3.1 9.0 1.8 4.0 1450 58.2 3.60 4.7 46.0 107.2 59.8 4.9
9.0 1.8 4.0 1550 53.5 36.0 2.69 19.9 62.7 83.9 3.1 9.0 1.8 4.0 1650 59.1 3.49 5.0 47.2 103.2 59.5 5.0
12.0 3.3 7.6 1360 53.2 33.6 2.51 21.2 61.6 80.3 2.8 12.0 3.3 7.6 1450 59.7 3.64 4.8 47.3 108.1 62.1 5.0
12.0 3.3 7.6 1550 54.1 36.1 2.60 20.8 63.0 80.5 2.9 12.0 3.3 7.6 1650 60.6 3.53 5.0 48.6 104.0 61.9 5.1
80
6.0 0.7 1.5 1360 48.1 31.8 3.07 15.7 58.6 99.5 4.5 6.0 0.7 1.5 1450 60.7 3.67 4.8 48.2 108.8 63.9 5.1
6.0 0.7 1.5 1550 49.0 34.2 3.18 15.4 59.8 99.9 4.6 6.0 0.7 1.5 1650 61.6 3.56 5.1 49.5 104.6 63.5 5.2
9.0 1.7 4.0 1360 50.1 32.7 2.87 17.5 59.9 93.3 3.8 6.5 0.8 1.9 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
9.0 1.7 4.0 1550 51.0 35.1 2.97 17.2 61.1 93.6 3.9 6.7 0.9 2.1 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
12.0 3.2 7.5 1360 51.1 33.0 2.77 18.4 60.4 90.1 3.6 6.5 0.8 1.9 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
12.0 3.2 7.5 1550 51.9 35.5 2.87 18.1 61.7 90.3 3.6 6.7 0.9 2.1 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
90
6.0 0.7 1.5 1360 44.9 30.2 3.40 13.2 56.5 108.8 4.8 3.9 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
6.0 0.7 1.5 1550 45.7 32.5 3.52 13.0 57.7 109.2 4.9 4.0 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
9.0 1.7 3.9 1360 47.1 31.3 3.17 14.8 57.9 102.9 4.5 3.9 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
9.0 1.7 3.9 1550 47.9 33.6 3.29 14.6 59.1 103.1 4.6 4.0 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
12.0 3.2 7.4 1360 48.1 31.8 3.07 15.7 58.5 99.8 5.6 3.9 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
12.0 3.2 7.4 1550 49.0 34.2 3.18 15.4 59.8 100.0 5.7 4.0 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
100
6.0 0.6 1.5 1360 41.7 28.6 3.77 11.1 54.6 118.2 5.9 2.8 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
6.0 0.6 1.5 1550 42.5 30.8 3.91 10.9 55.8 118.6 6.0 2.9 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
9.0 1.7 3.8 1360 43.7 29.6 3.52 12.4 55.8 112.4 5.6 2.8 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
9.0 1.7 3.8 1550 44.5 31.8 3.65 12.2 57.0 112.7 5.7 2.9 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
12.0 3.2 7.3 1360 44.8 30.1 3.41 13.2 56.4 109.4 6.8 2.8 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
12.0 3.2 7.3 1550 45.6 32.4 3.53 12.9 57.6 109.6 7.0 2.9 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
110
6.0 0.6 1.4 1360 38.9 27.3 4.23 9.2 53.4 127.8 7.3 2.2 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
6.0 0.6 1.4 1550 39.5 29.3 4.38 9.0 54.5 128.2 7.4 2.2 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
9.0 1.6 3.7 1360 40.6 28.0 3.95 10.3 54.0 122.0 6.8 2.2 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
9.0 1.6 3.7 1550 41.3 30.2 4.09 10.1 55.2 122.3 7.0 2.2 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
12.0 3.1 7.2 1360 41.5 28.5 3.80 10.9 54.5 119.1 8.3 2.2 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
12.0 3.1 7.2 1550 42.2 30.6 3.94 10.7 55.7 119.3 8.4 2.2 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
120
6.0 0.6 1.3 1360 36.8 26.6 4.79 7.7 53.2 137.7 8.8 1.8 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
6.0 0.6 1.3 1550 37.4 28.6 4.96 7.5 54.3 138.1 9.0 1.8 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
9.0 1.6 3.6 1360 37.9 26.9 4.44 8.5 53.1 131.8 8.3 1.8 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
9.0 1.6 3.6 1550 38.6 28.9 4.60 8.4 54.3 132.1 8.5 1.8 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
12.0 3.0 7.0 1360 38.6 27.2 4.27 9.0 53.3 128.9 8.3 1.8 0.1 0.2 1450 61.6 3.70 4.9 49.0 109.4 65.0 5.2
12.0 3.0 7.0 1550 39.3 29.2 4.43 8.9 54.4 129.1 8.5 1.8 0.1 0.2 1650 62.6 3.59 5.1 50.3 105.1 65.0 5.3
Interpolation is permissible; extrapolation is not. All performance is based upon the lower voltage of dual voltage rated units.
Flow is controlled to maintain minimum LWT 70° F in cooling and maximum LWT 65° F in heating. Operation at or below 40° F EWT is based on 15% methanol antifreeze solution.
Table does not refl ect fan or pump power corrections for AHRI/ISO conditions. See Performance correction tables for operating conditions other than those listed above.
For operation in the shaded areas, please see the Performance Data Selection Notes.
Refer to the Tranquility
®
30 Digital Product Catalog for unit performance at Part Load operation and for performance data without vFlow
™
.
