Table 17d: Performance Data — Tranquility
®
30 Digital - Model - 064
Full Load - with vFlow
™
Performance capacities shown in thousands of Btuh Antifreeze use recommended in this range. Also Clip JW3 on DXM2 board.
EWT
°F
Cooling - EAT 80/67 °F Heating - EAT 70°F
GPM
WPD
CFM TC SC kW EER HR LWT HWC GPM
WPD
CFM HC kW COP HE LAT LWT HWC
PSI FT PSI FT
20
3.3 0.2 0.4 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 15.0 7.3 16.8 1800 42.8 3.89 3.2 29.8 92.0 16.0 3.8
3.4 0.2 0.2 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 15.0 7.3 16.8 2050 43.4 3.77 3.4 30.6 89.6 15.9 3.8
30
4.2 0.1 0.2 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 7.5 1.7 3.9 1800 46.9 3.95 3.5 33.6 94.1 21.0 3.9
4.2 0.1 0.2 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 7.5 1.7 3.9 2050 47.6 3.82 3.6 34.5 91.5 20.8 4.0
4.2 0.1 0.1 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 11.3 3.7 8.6 1800 49.1 3.98 3.6 35.8 95.3 23.6 4.0
4.2 0.1 0.1 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 11.3 3.7 8.6 2050 49.9 3.86 3.8 36.7 92.5 23.5 4.1
4.2 0.1 0.2 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 15.0 6.1 14.1 1800 50.4 4.00 3.7 36.9 95.9 25.1 4.0
4.2 0.1 0.2 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 15.0 6.1 14.1 2050 51.2 3.88 3.9 37.9 93.1 24.9 4.1
40
5.5 0.3 0.6 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 7.5 1.2 2.7 1800 53.9 4.06 3.9 40.2 97.7 29.3 4.2
5.7 0.3 0.2 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 7.5 1.2 2.7 2050 54.7 3.94 4.1 41.3 94.7 29.0 4.2
5.5 0.3 0.6 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 11.3 3.0 7.0 1800 56.7 4.12 4.0 42.8 99.2 32.4 4.3
5.7 0.3 0.8 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 11.3 3.0 7.0 2050 57.6 3.99 4.2 44.0 96.0 32.2 4.4
5.5 0.3 0.6 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 15.0 5.3 12.2 1800 58.3 4.15 4.1 44.3 100.0 34.1 4.3
5.7 0.3 0.8 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 15.0 5.3 12.2 2050 59.2 4.02 4.3 45.5 96.7 33.9 4.4
50
7.5 0.9 2.0 1630 72.4 47.8 3.08 23.5 82.8 72.1 2.8 7.5 0.9 2.0 1800 61.1 4.21 4.3 46.9 101.5 37.5 4.5
7.5 0.9 2.0 1850 73.6 51.4 3.20 23.0 84.5 72.5 2.9 7.5 0.9 2.0 2050 62.1 4.08 4.5 48.2 98.0 37.2 4.6
8.3 1.2 2.8 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 11.3 2.6 6.0 1800 64.5 4.28 4.4 50.0 103.2 41.1 4.6
8.5 1.3 3.0 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 11.3 2.6 6.0 2050 65.5 4.15 4.6 51.3 99.6 40.9 4.7
8.3 1.2 2.8 1630 73.0 48.1 3.02 24.2 83.2 70.0 2.7 15.0 4.7 10.8 1800 66.3 4.32 4.5 51.7 104.1 43.1 4.7
8.5 1.3 3.0 1850 74.3 51.7 3.13 23.7 85.0 70.0 2.8 15.0 4.7 10.8 2050 67.3 4.19 4.7 53.0 100.4 42.9 4.8
60
7.5 0.7 1.7 1630 69.5 46.7 3.35 20.7 80.9 81.6 3.5 7.5 0.7 1.7 1800 68.5 4.37 4.6 53.6 105.2 45.7 4.9
7.5 0.7 1.7 1850 70.7 50.3 3.47 20.4 82.6 82.0 3.6 7.5 0.7 1.7 2050 69.5 4.24 4.8 55.1 101.4 45.3 5.0
11.3 2.4 5.4 1630 71.7 47.6 3.15 22.8 82.3 74.6 3.0 11.3 2.4 5.4 1800 72.3 4.46 4.7 57.1 107.2 49.8 5.1
11.3 2.4 5.4 1850 73.0 51.1 3.26 22.4 84.1 75.0 3.1 11.3 2.4 5.4 2050 73.4 4.33 5.0 58.6 103.2 49.6 5.2
15.0 4.3 10.0 1630 72.7 48.0 3.05 23.8 83.0 71.1 2.8 15.0 4.3 10.0 1800 74.4 4.52 4.8 59.0 108.3 52.1 5.2
15.0 4.3 10.0 1850 74.0 51.6 3.16 23.4 84.8 71.3 2.8 15.0 4.3 10.0 2050 75.5 4.38 5.1 60.6 104.1 51.9 5.3
70
7.5 0.7 1.7 1630 66.1 45.5 3.67 18.0 78.6 91.0 4.4 7.5 0.7 1.7 1800 75.8 4.55 4.9 60.3 109.0 53.9 5.3
7.5 0.7 1.7 1850 67.3 48.9 3.81 17.7 80.3 91.4 4.5 7.5 0.7 1.7 2050 77.0 4.41 5.1 61.9 104.8 53.5 5.4
11.3 2.3 5.2 1630 68.6 46.4 3.43 20.0 80.3 84.2 3.8 11.3 2.3 5.2 1800 80.1 4.67 5.0 64.2 111.2 58.6 5.6
11.3 2.3 5.2 1850 69.8 49.9 3.56 19.6 82.0 84.6 3.8 11.3 2.3 5.2 2050 81.3 4.52 5.3 65.9 106.7 58.3 5.7
15.0 4.1 9.5 1630 69.9 46.9 3.32 21.0 81.1 80.8 3.5 15.0 4.1 9.5 1800 82.4 4.73 5.1 66.3 112.4 61.2 5.7
15.0 4.1 9.5 1850 71.1 50.4 3.44 20.6 82.8 81.0 3.5 15.0 4.1 9.5 2050 83.7 4.59 5.3 68.0 107.8 60.9 5.8
80
7.5 0.8 1.8 1630 62.5 44.1 4.05 15.4 76.2 100.3 5.5 7.5 0.8 1.8 1800 83.1 4.75 5.1 66.9 112.8 62.2 5.8
7.5 0.8 1.8 1850 63.5 47.5 4.19 15.1 77.8 100.8 5.6 7.5 0.8 1.8 2050 84.4 4.61 5.4 68.7 108.1 61.7 5.9
11.3 2.2 5.2 1630 65.1 45.1 3.78 17.2 77.9 93.8 4.7 9.3 1.4 3.3 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
11.3 2.2 5.2 1850 66.2 48.5 3.91 16.9 79.6 94.1 4.8 9.5 1.5 3.6 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
15.0 4.1 9.4 1630 66.4 45.6 3.65 18.2 78.7 90.5 4.3 9.3 1.4 3.3 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
15.0 4.1 9.4 1850 67.5 49.0 3.78 17.9 80.4 90.7 4.4 9.5 1.5 3.6 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
90
7.5 0.8 2.0 1630 58.7 42.6 4.49 13.1 74.0 109.7 6.7 5.6 0.2 0.4 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
7.5 0.8 2.0 1850 59.8 45.8 4.65 12.9 75.6 110.2 6.8 5.7 0.2 0.5 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
11.3 2.3 5.2 1630 61.3 43.7 4.18 14.7 75.5 103.4 5.8 5.6 0.2 0.4 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
11.3 2.3 5.2 1850 62.3 47.0 4.33 14.4 77.1 103.7 5.9 5.7 0.2 0.5 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
15.0 4.0 9.3 1630 62.6 44.2 4.03 15.5 76.3 100.2 5.4 5.6 0.2 0.4 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
15.0 4.0 9.3 1850 63.7 47.5 4.18 15.2 77.9 100.4 5.5 5.7 0.2 0.5 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
100
7.5 0.9 2.0 1630 55.2 41.1 5.00 11.0 72.3 119.3 8.1 4.0 0.1 0.2 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
7.5 0.9 2.0 1850 56.2 44.2 5.18 10.8 73.9 119.7 8.3 4.1 0.1 0.2 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
11.3 2.3 5.2 1630 57.5 42.1 4.65 12.4 73.4 113.0 7.1 4.0 0.1 0.2 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
11.3 2.3 5.2 1850 58.5 45.3 4.82 12.1 75.0 113.3 7.3 4.1 0.1 0.2 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
15.0 4.0 9.3 1630 58.8 42.6 4.48 13.1 74.0 109.9 6.7 4.0 0.1 0.2 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
15.0 4.0 9.3 1850 59.8 45.9 4.65 12.9 75.6 110.1 6.8 4.1 0.1 0.2 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
110
7.5 0.8 1.8 1630 52.2 39.6 5.60 9.3 71.4 129.0 9.8 3.1 0.1 0.1 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
7.5 0.8 1.8 1850 53.1 42.6 5.80 9.2 72.9 129.4 10.0 3.2 0.1 0.1 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
11.3 2.2 5.1 1630 54.1 40.6 5.20 10.4 71.9 122.7 8.7 3.1 0.1 0.1 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
11.3 2.2 5.1 1850 55.0 43.6 5.39 10.2 73.4 123.1 8.8 3.2 0.1 0.1 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
15.0 4.0 9.2 1630 55.2 41.1 5.01 11.0 72.3 119.6 8.2 3.1 0.1 0.1 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
15.0 4.0 9.2 1850 56.1 44.2 5.19 10.8 73.8 119.8 8.3 3.2 0.1 0.1 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
120
7.5 0.6 1.3 1630 50.0 38.5 6.30 7.9 71.6 139.1 11.7 2.5 0.1 0.1 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
7.5 0.6 1.3 1850 50.8 41.4 6.53 7.8 73.1 139.5 11.9 2.6 0.1 0.1 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
11.3 2.0 4.7 1630 51.3 39.2 5.83 8.8 71.3 132.6 10.4 2.5 0.1 0.1 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
11.3 2.0 4.7 1850 52.2 42.1 6.04 8.6 72.8 132.9 10.6 2.6 0.1 0.1 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
15.0 3.8 8.8 1630 52.1 39.6 5.62 9.3 71.3 129.5 9.8 2.5 0.1 0.1 1800 86.0 4.84 5.2 69.5 114.3 65.0 6.0
15.0 3.8 8.8 1850 53.0 42.6 5.82 9.1 72.9 129.7 10.0 2.6 0.1 0.1 2050 87.3 4.69 5.5 71.3 109.4 65.0 6.1
Interpolation is permissible; extrapolation is not. All performance is based upon the lower voltage of dual voltage rated units.
Flow is controlled to maintain minimum LWT 70° F in cooling and maximum LWT 65° F in heating. Operation at or below 40° F EWT is based on 15% methanol antifreeze solution.
Table does not refl ect fan or pump power corrections for AHRI/ISO conditions. See Performance correction tables for operating conditions other than those listed above.
For operation in the shaded areas, please see the Performance Data Selection Notes.
Refer to the Tranquility
®
30 Digital Product Catalog for unit performance at Part Load operation and for performance data without vFlow
™
.
