ClimateMaster Tranquility TCV 024 User Manual

ClimateMaster Water-Source Heat Pumps
42
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
Blower Performance Data – TC018
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
600 450 PSC
Low CFM 524 509 493 451
Medium CFM 611 588 564 514
High CFM 704 668 643 617 504
600 450
PSC -
High
Static
Low CFM 461
Medium CFM 553 543 533 506 468
High CFM 670 661 645 628 587 534
600 450
ECM -
Constant
Torque
1
RPM 693 763 837 882
Power (W) 73 78 85 90
CFM 600 558 518 491
2
RPM 745 801 873 904 966 1031 1098
Power (W) 92 99 107 109 116 123 131
CFM 676 641 599 570 536 498 452
3
RPM 782 831 890 958 992 1048 1106 1171 1223
Power (W) 112 118 126 135 140 147 155 163 170
CFM 741 713 677 640 619 586 554 512 471
4
RPM 833 875 924 986 1046 1072 1124 1177 1236 1290
Power (W) 138 144 152 161 170 174 181 190 199 207
CFM 802 780 751 714 680 662 633 603 567 529
5
RPM 895 924 968 1016 1078 1133 1151 1199 1249 1302
Power (W) 170 175 182 190 201 210 214 222 231 240
CFM 854 848 820 791 754 724 711 683 655 625
600 450
ECM -
Constant
Volume
Minimum CFM
RPM 1096 1179 1275 1361
Power (W) 111 132 157 180
CFM 450 450 450 450
Default CFM
RPM 847 918 971 1095 1208 1297 1360 1418 1467
Power (W) 85 101 113 145 178 206 228 248 266
CFM 600 600 600 600 600 600 600 600 600
Maximum CFM
RPM 1036 1080 1131 1172 1213 1317 1406 1494
Power (W) 157 171 186 200 214 251 286 323
CFM 750 750 750 750 750 750 750 750
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.

ClimateMaster Tranquility TCV 024 Specifications

General

Model Number	TCV024
Category	Heat Pump
Phase	1
Refrigerant	R-410A
Cooling Capacity	2 Tons
Cooling Capacity (BTU/h)	24000
Voltage (VAC)	208/230
