climatemaster.com
77
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Start-Up Log Sheet
Installer: Complete unit and system checkout and follow unit start-up procedures in the IOM. Use this form to record
unit information, temperatures and pressures during start-up. Keep this form for future reference.
Job Name: Street Address:
Model Number: Serial Number:
Unit Location in Building:
Date: Sales Order No:
In order to minimize troubleshooting and costly system failures, complete the following checks and data entries before
the system is put into full operation.
Fan Motor Description Value
PSC Speed Tap
CT ECM Speed Tap
CV ECM CFM Setting
Temperatures: F or C Antifreeze: %
Pressures: PSIG or kPa Type:
Cooling Mode Heating Mode
Entering Fluid Temperature
Leaving Fluid Temperature
Temperature Differential
Return-Air Temperature DB WB DB
Supply-Air Temperature
DB
WB DB
Temperature Differential
Water Coil Heat Exchanger
(Water Pressure IN)
Water Coil Heat Exchanger
(Water Pressure OUT)
Pressure Differential
Water Flow GPM
Compressor
Amps
Volts
Discharge Line Temperature
Motor
Amps
Volts
Allow unit to run 15 minutes in each mode before taking data.
Note: Never connect refrigerant gauges during startup procedures. Conduct water-side analysis using P/T ports to determine water ow and temperature difference. If
water-side analysis shows poor performance, refrigerant troubleshooting may be required. Connect refrigerant gauges as a last resort.
