Page #18 background imageLoading...
Page #18 background image
18
CHA
5.2.2 Evaporatore
È di importanza fondamentale che l’ingresso dell’ac-
qua avvenga in corrispondenza della connessione
contrassegnata con la targhetta “ENTRATA ACQUA”.
Per gli attacchi idraulici vengono utilizzate connessioni filettate
maschio o flangiate, a seconda dei modelli (fare riferimento ai di-
segni dimensionali, così come per la posizione degli attacchi).
È di fondamentale importanza realizzare il circuito idrau-
lico in modo tale che venga garantita la costanza della
portata d’acqua allo scambiatore in qualsiasi condizione
di funzionamento. Una portata d’acqua non costante può
essere accettata solo nelle unità con desurriscaldatori.
Poiché la richiesta frigorifera dell’utenza non coincide
generalmente con quella erogata dai compressori,
l’azione degli stessi è molto spesso intermittente. Negli
impianti a basso contenuto d’acqua, dove l’effetto di
inerzia termica della stessa è meno sensibile, è oppor-
tuno verificare che il contenuto dell’impianto soddisfi la
seguente relazione: V > P/115n
dove:
V = volume d’acqua (litri)
P = potenza resa dall’unità (Watt)
n = numero di gradini di parzializzazione.
Se non vengono raggiunti i volumi sopraccitati, è necessario
prevedere un serbatoio d’accumulo tale che, sommato alla
capacità dell’impianto, venga raggiunto il valore fornito dalla
relazione riportata. Tale serbatoio non richiede particolari
accorgimenti, salvo che, allo stesso modo delle tubature
dell’acqua refrigerata, va isolato al fine di non penalizzare la
resa dell’impianto e di evitare fenomeni di condensazione.
È buona norma installare una valvola di sicurezza sul circu-
ito idraulico (se non già presente). In caso di anomalie gravi
nell’impianto (ad es. incendio) essa permetterà di scaricare
il sistema evitando possibili scoppi. Collegare sempre lo
scarico ad una tubazione di diametro non inferiore a quello
dell’apertura della valvola, e convogliarlo in zone nelle quali
il getto non possa recare danno alle persone.
Attenzione!
Durante le operazioni di allacciamento idraulico non operare
mai con fiamme libere in prossimità o all’interno dell’unità.
5.3 COLLEGAMENTI ELETTRICI
5.3.1 Generalità
Queste operazioni devono essere effettuate
solo da personale specializzato.
Prima di effettuare qualsiasi operazione su
parti elettriche assicurarsi che non vi sia
tensione.
Verificare che l’energia disponibile corrisponda ai dati nomi-
nali dell’unità riportati sulla targhetta (tensione, numero di fasi,
5.2.2 Evaporator
It is vitally important that the water enters
the unit from the connection point marked
with the “WATER INLET” plate.
Threaded or flanged male unions, depending on the models,
are used to make water connections (please refer to the scale
drawings which also show the position of the unions).
It is vitally important to connect the water circuit
so that the flow of water to the exchanger is
always constant under all operating conditions.
A variable flow of water is only accepted for
units with the desuperheaters.
As the demand for cooling by utilities does not gener-
ally coincide with what is delivered by the compressors,
they often work intermittently. In units with a low water
content, where the effect of thermal inertia is not felt so
much, the system should be checked to make sure it
satisfies the following relation:
V > P/115n
where:
V = volume of water (litres)
P = power capacity of the unit (Watts)
n = number of capacity steps.
If the above volumes are not obtained, a storage tank
should be installed so as to satisfy the above relation
when added to the capacity of the system.
This tank requires no special features; it just needs to
be isolated, just like the chilled water pipes, so as not
to affect the performance of the system and to prevent
the formation of condensation.
A safety valve should be installed on the water circuit
(if not already fitted). In case of serious system faults
(e.g. fire) this will allow the system to be drained
in order to prevent the risk of explosions. Always
connect the drain to a pipe with a diameter not less
than that of the valve opening and install the outlet in
an area where the jet cannot cause harm to people.
Attention!
While connecting the water circuit, never work
with naked flames near to or inside the unit.
5.3 ELECTRICAL CONNECTIONS
5.3.1 General
These operations may only be carried out
by specialised staff.
Before carrying out any operations on elec-
trical components, make sure the unit is
disconnected from the mains power supply.
Make sure that the mains power supply corresponds to the
rated values of the unit shown on the plate (voltage, number of
