General technical data
Size 7.1 10.1 14.2
Cooling
Cooling capacity 1 kW 20,6 30,4 45,7
Sensible capacity 1 kW 16,5 24,6 35,9
Compressor power input 1 kW 5,27 8,28 11,5
EER 1 3,91 3,67 3,97
Heating
Heating capacity 2 kW 20,9 29,8 43,8
Compressor power input 2 kW 5,08 7,24 9,89
COP 2 4,11 4,12 4,43
Compressor
Type of compressors 3 Rot Scroll Rot
No. of compressors Nr 1 1 2
Std Capacity control steps Nr 20-100% 20-100% 20-100%
Refrigerant charge (C1) 4 kg 7,0 10,0 13,0
Refrigeration circuits Nr 1 1 1
Air Handling Section Fans (Supply)
Type of supply fan 5 RAD RAD RAD
Number of supply fans Nr 1 1 1
Fan diameter mm 450 500 560
Type of motor 6 EC Brushless EC Brushless EC Brushless
Supply airow l/s 1111 1667 2500
Supply airow m
3
/h 4000 6000 9000
Installed unit power kW 1,0 2,6 2,9
Max. static pressure supply fan 7 Pa 380 680 510
Fans (Exhaust)
Type of exhaust fan 5 RAD RAD RAD
Number of exhaust fans 8 Nr 1 1 1
Fan diameter 8 mm 355 355 450
Type of motor 6 EC Brushless EC Brushless EC Brushless
Installed unit power 8 kW 0,9 0,9 1,0
External Section Fans
Type of fans 9 AX AX AX
Number of fans Nr 1 1 1
Fan diameter mm 750 750 780
Fan RPM 6 EC Brushless EC Brushless EC Brushless
Standard airow l/s 2361 3500 5833
Installed unit power kW 0,65 0,75 1,5
Connessioni
Scarico condensa mm 20 20 20
Power supply
Standard power supply V 400/3/50+N 400/3/50+N 400/3/50+N
Performance data are referred to operation with 30% of fresh air intake and same amount of air exhaust. (conguration CCK)
1. Ambient air at 27°C/19°C W.B.. external exchanger entering air temperature 35°C. EER referred only to compressors
2. Ambient air 20°C D.B. Outdoor air 7°C D.B./6°C W.B.. COP referred only to compressors
3. ROT = compressore rotativo; SCROLL = scroll compressor
4. Indicative values for standard units with possible +/-10% variation. The actual data are indicated on the label of the unit
5. RAD = radial fan
6. EC Electronic switching motor
7. Net outside static pressure to win the outlet and intake onboard pressure drops
8. Conguration for fresh air supply with exhaust and extraction
9. AX = axial fan
M06K10A18-00 CKN-XHE2i 7.1-14.2 56
