CLIVET ELFOROOM 15 - General Technical Specifications; Electrical Data; Operating Limits (Heating); Operating Limits (Cooling)

9 - TECHNICAL INFORMATION
GENERAL TECHNICAL SPECIFICATIONS
Voltage: 230/1/50
ELECTRICAL DATA
Size
3 5 11 15 17
COOLING
Cooling capacity 1 kW 0,83 1,76 2,65 3,34 3,8
Sensible capacity 1 kW 0,62 1,27 1,96 2,65 3,01
Total power input 1 kW 0,012 0,018 0,02 0,027 0,03
HEATING
Heating capacity 2 kW 0,94 1,98 2,72 3,46 4,12
INTERNAL EXCHANGER
Water content l 0,47 0,8 1,13 1,46 1,8
Water flow-rate 1 l/s 0,04 0,084 0,125 0,16 0,182
Pressure drop 1 kPa 7,2 8,4 22,5 18,6 24,9
AIR HANDLING SECTION FANS (OUTLET)
Type of supply fan 3 TGZ TGZ TGZ TGZ TGZ
Supply air flow rate 4 l/s 45 89 128 160 180
CONNECTIONS
Water fittings Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4
Condensate discharge
14 14 14 14 14
POWER SUPPLY
Standard power supply V 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
(1) Ambient temperature 27°C/19.5 WB
water inlet 7°C and outlet 12°C
(2) Ambient temperature 27°C/19.5 WB
water inlet 7°C and outlet 12°C
(3) Ambient temperature 20°C DB
water inlet 45°C and outlet 40°C
(4) TGZ=tangential
(5) Air flow at max speed measured with clean filters
Size
3 5 11 15 17
F.L.A. - FULL LOAD CURRENT AT MAX ADMISSIBLE CONDITIONS
F.L.A. - Total
A 0,11 0,16 0,18 0,26 0,28
F.L.I. FULL LOAD POWER INPUT AT MAX ADMISSIBLE CONDITION
F.L.I. - Total
kW 0,012 0,018 0,02 0,027 0,03
power supply 230/1/50 Hz +/-10%
OPERATING LIMITS (COOLING)
Size
3 5 11 15 17
EXTERNAL EXCHANGER
Max inlet water temperature
°C 20 20 20 20 20
Min. water inlet temperature
°C 4 4 4 4 4
Maximum water side pressure
bar 10 10 10 10 10
OPERATING LIMITS (HEATING)
INTERNAL EXCHANGER
Max inlet water temperature
°C 80 80 80 80 80
Min. water inlet temperature
°C 30 30 30 30 30
Max. air temperature inlet (D.B.)
°C 40 40 40 40 40
Min. air temperature inlet (D.B.)
°C 5 5 5 5 5
Size
3 5 11 15 17
84
