Remote LCD Screen Indicators
Information are dis played when the remote controller is powered up.
Transmission Indicator
Sleep mode display
Follow me feature
display
Not availa
ble
for
this unit
Not available for
this u
nit
Silence feature
display
Lights up when remote
sends signal to indoor
unit
ON/OFF display
Appears when the unit
is turned on, and disappears
when the it is turned o.
TIMER ON display
( )
( )
MODE display
Displays the current
mode, including:
Displays when TIMER
ON is set
TIMER OFF display
Displays when TIMER
OFF is set
Note:
All indicators shown in the figure are for the purpose of clear presentation. But during the actual
operation only the relative functional signs are shown on the display window.
Not availa
ble
for
this unit
Fresh feature display
Horizontal louver auto swing display
Vertical louver auto swing display
Wind ow follow people
Wind ow away from people
Turbo mode display
LOCK feature display
Displays when ECO
feature is activated
Battery display
Low battery detection
Temperature/Timer/Fan
speed display
Displays the set temperature
by default, fan speed or
timer setting when using
TIMER ON/OFF functions
Temperature range:
oO
16-30 C/60-86 F
Timer setting range:
0-24 hours
Fan speed setting range:
AU -F%
This display is blank when
operating in FAN mode.
Fan speed display
Displays selected fan speed:
This fan speed can not be
adjusted in AUTO or DRY
mode.
