CLIVET WSAN-EE 21 - OPERATING LIMITS

M02R40C8-00 29/07/08 page 50
OPERATING LIMITS (Cooling)
Size
17 21 25 31 41 51 61 71 81 91 101 121 131 151
EXTERNAL EXCHANGER
Max air intake temperature 1 °C 51 50 49 50 52 49 47 45 46 46 45 46 47 45
INTERNAL EXCHANGER
Max water inlet temperature 2 °C 21 21 22 22 22 22 23 23 23 23 23 23 23 23
Min. water outlet temperature 3 °C 3 3 3 3 3 3 3 3 3 3 3 3 3 3
OPERATING LIMITS (Heating)
Size
17 21 25 31 41 51 61 71 81 91 101 121 131 151
EXTERNAL EXCHANGER
Max air temperature inlet
(WB)
4 °C 25 25 25 25 25 25 25 25 25 25 25 25 25 25
Min air inlet temperature
(W.B.)
°C -15 -15 -15 -15 -15 -15 -14 -14 -15 -15 -13 -15 -15 -15
INTERNAL EXCHANGER
Max water inlet temperature 6 °C 48 49 51 51 51 51 50 51 51 51 50 51 52 52
Min. water inlet temperature 7 °C 20 20 20 20 20 20 20 20 20 20 20 20 20 20
water thermal head = 5°C
Min/max temperature Delta=3/8°C
ATTENTION: IN CASE OF PREDOMINANT WINDS, WINDBREAK BARRIERS ARE NECESSARY.
Data refer to unit operating with fans at max. flow-rate. It follows an energy efficiency increase, but also a sound pressure increase of about 2/3 dB(A).
(1) internal exchanger water = 12/7°C
(2) external exchanger air intake 30°C
Maximum exchanger inlet water temperature 32°C during max. 15 minutes, thanks to the variable flow rate device for the circulator (standard).
(size 61-71-81-91-101-121)
(3) Antifreeze (std)
(4) Data referred to still air
internal exchanger water = 40/45°C
Internal exchanger water outlet temperature=38°C
(6) room temperature = 7°C (RH = 85%)
(7) Minimum water temperature at exchanger inlet 14°C during max. 15 minutes, thanks to the variable flow rate device of the circulator (standard).
(size 61-71-81-91-101-121)
INTEGRATED HEATING CAPACITIES
External exchanger inlet temperature °C (D.B. / W.B.) -5 / -5.4 0 / -0.6 5 / 3.9
A
LTRI
heating capacity multiplication coefficient 0,89 0,88 0,94 1
To obtain the integrated heating capacities (the real heating capacity considering the defrost cycles too), multiply the kWt value in the heating performance tables by the following
coefficient..
