M02R40C8-00 29/07/08 page 49
EXPANSION VESSEL
Expansion vessel capacity l 1 1 1 2 2 2 5 5 5 5 5 5 5 5
No. of expansion vessels Nr 1 1 1 1 1 1 1 1 1 1 1 1 1 1
POWER SUPPLY
Standard power supply V 230/1/50 400/3/50+N
NOISE LEVELS
Sound pressure level (1 m) dB(A) 49 49 51 53 53 55 62 62 63 63 63 64 65 66
DIMENSIONS
Length mm 800 800 800 800 800 800 1087 1087 1087 1087 1373 1373 1710 1710
Depth mm 300 300 300 300 300 300 411 411 411 411 555 555 684 684
Height mm 930 930 930 930 1244 1244 1175 1175 1175 1175 1225 1225 1477 1477
Packing volume m
3
0.43 0.43 0.43 0.43 0.55 0.55 0.66 0.66 0.66 0.66 1.14 1.14 2.13 2.13
STANDARD UNIT WEIGHTS
Shipping weight kg 70 78 79 93 113 122 132 135 180 184 203 206 275 280
Operating weight kg 68 76 77 91 111 120 126 129 174 178 198 201 268 273
Shown datas are referred to units working in perfect installation and exchangers' cleaning conditions.
(1) data referred to the following conditions :
internal exchanger water = 12/7°C
external exchanger air intake 35°C
(2) Total input is obtained from compressor input + fan input
(3) EER calculated as the relationship between cooling capacity and total absorbed power.
(4) data referred to the following conditions :
External air temperature : 7°C D.B./6.0°C W.B.
internal exchanger water = 40/45°C
(5) COP calculated as the relationship between heating capacity and total absorbed power.
(7) ROT = rotary compressor
SCROLL = scroll compressor
(6) The indicated COP values were calculated in compliance with the provisions of standard EN 14511:2004.
(8) Nominal values
(9) PHE = plates
(10) AX = axial-flow fan
