M01W45H6-06
WSAT-SC
75C-180F
- CONTROL -
42
COMPRESSOR MODULE
Str Name
16 E101 Cond./ Evap. temp. probe fault
17 E102 Condensing pressure probe fault
18 E103 Evaporation pressure probe fault
19 E104 Recovery temp. probe fault
20 E105 High pressure alarm
21 E106 Low pressure alarm
22 E107 Fan/Pump thermal cut-out alarm
23 E111 Cond. / Evap. H2O flow alarm
24 E112 High pressure pre-alarm 1
25 E113 High pressure pre-alarm 2
26 E114 Low pressure pre-alarm
27 E115 Force defrost alarm
28 E116 Max Press. diff. alarm
29 E117 Recovery H2O flow alarm
30 E118 Heat recovery HP pre-alarm
31 E108 Compressor 1 thermal cut-out alarm
32 E109 Compressor 2 thermal cut-out alarm
33 E110 Compressor 3 thermal cut-out alarm
47 E213 Module not connected
49 E119 Oil differential pressure alarm
58 E120 Condenser frost alarm
E121 BP2 prealarm
E123 TEE inlet temp. alarm
E124 TEE discharge temp. alarm
E125 MaxTS TEE prealarm
E126 SPI Faulty alarm (TEE driver disconnection)
E127 Power Fail alarm
E128 Stepper Motor Error alarm
PUMP MODULE
Str Name Name
53 E501 Water flow probe fault
54 E502 Thermal pump 1alarm Pump Module
55 E503 Thermal pump 2alarm Pump Module
56 E504 Thermal pump 3alarm Pump Module
57 E505 Max flow-rate signal Pump Module
RECOVERY EXPANSION MODULE
Name
50 E301 Out recovery probe alarm
51 E302 Gas temperature probe alarm
EVAPORATOR MODULE
Str Name Name
34 E201 Evaporator inlet probe fault
35 E202 Evaporator outlet probe 1 fault
36 E202 Evaporator outlet probe 2 probe fault
37 E203 Programmable evaporator input alarm
38 E204 Thermal cut-out alarm, evaporator pump 1
39 E205 Thermal cut-out alarm, evaporator pump 2
40 E206 Evaporator flow switch alarm
41 E207 Evaporator system fill alarm
42 E208 Change pumps on evaporator
43 E209 Antifreeze alarm on evaporator
44 E210 Tout 1, antifreeze pre-alarm on evaporator
45 E211 Tout 2, antifreeze pre-alarm on evaporator
46 E212 System pump lockout
48 E214 Module not connected
