Excellence version (EN)
General technical data (EN)
Acoustic Treatment: extremely low noise (EN)
Size 352 402 432 452 502 552 602 702 802
Cooling
Cooling capacity 1 kW 91,5 104 116 125 134 145 165 185 207
Compressor power input 1 kW 28,5 32,9 37,1 37,7 42,1 46,1 53,4 58,5 66,2
Total power input 2 kW 30,1 34,5 38,7 39,9 44,3 48,3 55,6 61,4 69,1
Total recovery heating capacity 3 kW 119 139 151 161 176 190 215 242 269
Partial recovery heating capacity 3 kW 30,0 34,2 38,2 40,6 44,2 48,0 55,1 60,8 68,8
EER 1 3,04 3,01 2,99 3,13 3,03 3,01 2,96 3,01 3,00
Cooling capacity (EN14511:2013) 4 kW 91,0 103 115 124 134 145 164 184 206
Total power input (EN14511:2013) 4 kW 30,6 35,2 39,3 40.6 44,9 48,9 56,4 62,0 69,9
EER (EN 14511:2013) 4 2,97 2,94 2,93 3,06 2,98 2,96 2,91 2,97 2,95
ESEER 4 4,08 4,22 4,15 4,14 4,12 4,10 4,09 4,15 3,98
Compressor
Type of compressors SCROLL SCROLL SCROLL SCROLL
SCROLL SCROLL SCROLL SCROLL SCROLL
No. of compressors No 2 2 2 2 2 2 2 2 2
Rated power (C1) HP 35 40 43 45 50 55 60 70 80
Std Capacity control steps No 3 3 3 3 3 3 2 3 2
Oil charge (C1) l 8,00 10,0 12,0 10,0 11,0 13,0 13,0 13,0 13,0
Refrigerant charge (C1) 5 kg 28,3 28,3 31,9 39,5 39,5 39,5 44,6 51,3 57,9
Refrigeration circuits No 1 1 1 1 1 1 1 1 1
Internal exchanger
Type of internal exchanger 6 PHE PHE PHE PHE PHE PHE PHE PHE PHE
Water ow rate (Utility Side) 1 l/s 4,40 5,00 5,50 6,00 6,40 6,90 7,90 8,80 9,90
Internal exchanger pressure drops 1 kPa 26,8 26,9 28,0 32,1 30,8 35,1 37,3 36.3 38.1
Water content l 6.90 8.00 8.90 8.90 10.1 10.1 11.9 14.2 17.2
External Section Fans
Type of fans 7 AX AX AX AX AX AX AX AX AX
Number of fans No 2
2 2 3 3 3 3 4 4
Standard air ow l/s 9636 9571 9517 14358 14358 14253 14138 18925 18798
Connections
Water connections 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2
Power supply
Standard power supply V 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50
Dimensions
A - Length mm 3075 3075 3075 4025 4025 4025 4025 5025 5025
B - Width mm 1097 1097 1097 1097 1097 1097 1097 1097 1097
C - Height mm 1805 1805 1805 1805 1805 1805 1805 1805 1805
Standard unit weights
Shipping weight kg 889 925 1015 1198 1224 1246 1290 1483 1527
Operating weight kg 896 933 1024 1207 1234 1256 1302 1497 1544
1. Data referred to the following conditions: internal exchanger water = 12/7 °C external exchanger inlet air 35°C
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome the pressure drops
for the circulation of the solution inside the exchangers
3. Option. Recovery exchanger water = 40/45°C
4. Data calculated in compliance with Standard EN 14511:2013 referred to the following conditions: Internal exchanger water
temperature = 12/7°C. External exchanger intake air temperature = 35°C
5. indicative values for standard units with possible +/-10% variation. The actual data are indicated on the label of the unit.
6. PHE = plates
7. AX = axial fan
