Figure1-2 All icons indication interface
2. Technical Parameter
Name Technical Parameter
Rated Voltage 24V/33V/36V/48V/52V
Rated Current 24V/19mA, 33V/16mA, 36V/15.5mA, 48V/14.5mA, 52V/14.4mA
Ambient Temperature -20°C ~ +60°C
Ambient Humidity 0 ~ 100%RH
Protection Level IP65
Visible Angel of Screen Horizontal 160°, Vertical 160°
Table1 - Technical Parameter Sheet
3. Appearance &Dimensions
The standard bracket diameter is Ø31.8mm, we can provide the reduction sleeve of Ø22.2mm and
Ø25.4mm, to adapt to different handlebar size.
Figure3-1 Product dimensions
