Z4II & Z8II Installation and User Manual v1.0 1111
manuals with each item for guidance on how the outputs
should be connected to an unbalanced input.
However, the wiring methods shown in g.11 and g.12 will
work in a large number of cases. If hum or other distortion
is found to result, try disconnecting the ‘cold’ leg of the
balanced output (pin 3 on XLRs).
1
2
3
Unbalanced
input s
LEFT
RIGHT
+
+
SCN
SCN
+
+
SCN
SCN
When using single-core cable,
join ‘cold’ to screen at the
source
LEFT RIGHT
pin 1 ground
pin 2 hot
pin 3 cold
Balanced outputs (XLRs):
1
2
3
g.11: Balanced - Unbalanced input #1
Unbalanced
inputs
LEFT
RIGHT
+
+
-
-
SCN
SCN
+
+
-
-
SCN
SCN
When using twin-and-screen
cable, join ‘cold’t o screen at
DCM-1 end
LEFT RIGHT
pin 1 ground
pin 2 hot
pin 3 cold
Balanced outputs (XLRs):
1
2
3
1
2
3
g.12: Balanced - Unbalanced input #2
Zone outputs
Connect the inputs of the power ampliers feeding the
loudspeakers for each zone to ZONE 1 to 8*. Note that
the zone outputs are all mono. All outputs are balanced and
will drive input impedances down to 600 Ω. Nominal output
level is 0 dBu (775 mV). The output is designed to drive
professional/industrial power ampliers with balanced inputs
(typically on XLRs). In this case, wire as the diagram in g.13.
Note that the screen can be left unconnected at the source
end if earth loops are a problem.
*ZONE 1 to 4 only on Z4II.
1
3
+
-
+
-
SCN
pin1ground
pin2hot
pin3cold
Balanced outputs (XLRs):
12
3
2
SCSCN
Z8II/Z4II Balanced output:
pin 1 ground
pin 2 cold
pin 3 hot
The screen connection at the
zone end may be omitted if it
helps reduce earth loops
g.13: Balanced connection
Unbalanced inputs
If audio ampliers with only unbalanced inputs are being
used (e.g. hi- ampliers), the following wiring should be
adopted:
1
3
+
+
2
SCSCN
Z8II/Z4II Balanced output:
pin 1 ground
pin 2 cold
pin 3 hot
When using single-core cable,
don’t connect ‘cold’ at the
Z8
II/Z4II
Unbalanced input (e.g. phono)
g.14: Balanced output - Unbalanced input: using single-core screened cable
1
3
+
+
-
2
SCSCN
Z8II/Z4II Balanced output:
pin 1 ground
pin 2 cold
pin 3 hot
Unbalanced input (e.g. phono)
When using twin-and-screen
cable, don’t connect the screen
at the amplifier end.
-
g.15: Balanced output - Unbalanced input: using twin-core screened cable
