Cloud Z8II - Page 24

Z4II & Z8II Installation and User Manual v1.024
FRONT OF UNIT
POWER TRANSFORMERMOTHERBOARD (at bottom of chassis)ZONE SUB-CARDS
ZONE 8*
ZONE 1 ZONE 2 ZONE 3 ZONE 4
ZONE 5* ZONE 6* ZONE 7*
* Z8 II ONLY
KEY:
Jumper with two possible positions; black
square indicates factory default setting.
J1
J2
J3
J4
g.27: Jumper locations
SOCKET FOR
OPTIONAL BOSE® EQ CARD
(COMPONENT SIDE)
J1
J2
J3 J4
J5
J6
g.28: Sub-card jumper locations
