3DM580S USER MANUAL
www.cloudraymotor.com
※ The initial pulse is the testing pulse used when developing the drive software; Please refer to the actual
running direction of the motor.
4.3 Pulse filtering function selection
DIP SW6 is used to set the pulse filtering function of drive.
The “off” means the pulse filtering function is off;
The “on” means the pulse filtering function is on.
※ The pulse filtering function is the filtering action by the drive upon the input commands. When the filtering
function is on, the drive will smoothen the input pulse command to make the acceleration and deceleration of
motor softer, but this will also cause certain delay of the pulse command.
Filtering time setting: The default time of filtering function is 6.4ms, and the software can change the time
below the 25.6ms.
4.4 Pulse mode selection
DIP SW7 is used to set the pulse command mode of drives.
The “off” means pulse + direction (single pulse) mode; the “on” means double pulse mode.
※ When you need to set the drive pulse mode to A/B orthogonal pulse mode, set the pulse mode check
function to A/B orthogonal pulse mode in the testing software and turn on SW7.
4.5 Open/closed loop selection
DIP SW8 is used to set the drive control mode.
The “off” means the closed loop control mode;
The “on” means the open loop control mode.
※
※ The above parameters are set for the DIP switches; For other parameters, please refer to Appendix A:
Application Instructions for Testing Software
5. Drive working status LED indication
